Product details:
Applications: Food processing and other applications where motors receive washdown on a regular basis. Features: 300 series stainless steel hardware, moisture sealant on bolt heads, between frame and endplates. Neoprene gaskets. Double sealed ball bearings. Lip and V-Ring seal on drive end; slinger on ODE of TEFC motors. Stainless steel shaft extension. Electropproved surface coating, IP56 enclosure. Weatherproof per IEEE 45 and USCG 259 marine duty(below deck duty only), Class F insulated motor with 1.15 service factor. VWDL3507 HORSEPOWER 1 1/2 ENCLOSURE TEFC FRAME 145TC MOUNTING C-Face Footless NAMEPLATE RPM 1760 PHASE 3 MOTOR RPM 60Hz 1760 VOLTAGE 575 HERTZ 60 SERVICE FACTOR 1.15 AMBIENT TEMP C 40 WEIGHT 59 RPM RANGE 1701-1800 DESIGN CODE B BEARING-DRIVE-END 6205 BEARING-OPP-DRIVE-END 6203 FL EFFICIENCY 88.5 INSULATION CLASS F FL AMPS 1.7 KVA-CODE L 208V AMPS -- DOE-CODE 010A is_motor Yes ENCLOSURE TYPE Totally Enclosed POWER-FACTOR 76 DRIVE END FLANGE C-Face SERIAL-NUMBER -- C-DIMENSION INCHES 13.03 POLES 4 SPEC. NUMBER 05C053W830G1
